QX4-4000 4x1700 Watt Power Amplifier

The QX series of digital power amplifiers feature advanced amplifier adjustment technology to give over 95% efficiency, and stable performance at high current, low impedance conditions.

8ohms Stereo: 4x1000watts
4ohms Stereo: 4x1700watts
2ohms Stereo: 4x2890watts
16ohm Bridged: 2x2000watts
8ohm Bridged: 2x3400watts
4ohm Bridged: 2x5780watts

Additional features include active power factor correction (PFC) and ultra-reliable soft power switching power supply which will operate universally between 90-250VAC.

The QX series are all 1U height, lightweight designs, weighing less than 12kg. Both 2 and 4-channel versions are available, giving power ratings from 2550 watts per channel up to 5100 watts per channel at 4ohms.

Features

• Slope (1kHz, Bypass LPF): 50V/us • Input Sensitivity 1kHz: Option: 41dB, 38dB, 35dB, 32dB • THD+N (10% rated output power): 0.01% • IMD-SMPTE (10% rated output power): 0.01% • DIM30 (10% rated output power): 0.01% • Crosstalk rejection (less than rated power, 20Hz – 1kHz): >80Db • Frequency Response (10% rated output power, 8ohm, 20Hz – 20kHz): 0.2dB

• Input Impedance: 20k ohm (bal), 10k ohm (unbal) • Damping Factor (8ohm, 20Hz – 200Hz): 5000 • S/N ratio (A weighted, 20Hz-20kHz): >105-112dB • Power supply: 90-260VAC, 50/60Hz • Protection: low voltage/overoad/thermal/DC output protection • Dimensions (WxHxD) 483mm x 44mm x 462mm • Net Weight: 10-12kg
